Dräger X-am® 2800
The X-am® 2800 multi-gas detector measures up to four gases and is equipped with a particularly shock-resistant CatEx sensor. With the Dräger Gas Detection Connect software, it offers live data transmission and powerful fleet management. Designed for personal monitoring, the X-am® 2800 offers the highest level of safety at a low cost of ownership.
Summary
Product overview
1 to 4 gas detection devicefor personal air monitoringdetection of flammable gases and vapours as well as O2, CO, NO2, SO2 and H2SLive monitoring with Gas Detection Connect possible
Category
Portable Gas Detection
This page is structured from official Draeger content and reorganized for local B2B navigation.
Product enquiry
Enquire about Dräger X-am® 2800
Send your project, quantity or specification request directly from the product page. The lead will be stored in the site CRM and can also be routed to email and Telegram notifications.
Highlights
Structured product sections from the official source page.
360° Product View
Interactive or visual section carried over from the official product page.
Specifications
Technical groups extracted from the official Draeger detail page.
Specifications 1
- Measurable gases
- Ex, O2, CO, H2S or NO2 or SO2
- Sensorports
- 4
- Number of gases
- 1 - 4
- Sensor technology
- CAT + EC
Specifications 3
- Operation time
- >12h
- Dimensions (W × H × D)
- 4.8x13x4.4 cm
- Weight
- 220 g
- Battery type
- NiMh
- Degree of protection (IP class)
- IP 68
Specifications 5
- ATEX
- I M1 Ex da ia I Ma; II 1G Ex da ia IIC T4 Ga
- IECEx
- Ex da ia I Ma; Ex da ia IIC T4 Ga
- c CSA us
- Class I Div. 1 Group A, B, C, D, E, F, G T4/T3 | A/Ex da ia IIC T4/T3 /Ga
Specifications 6
- Name
- More information
- Acetic Acid
- More information
- Acetic acid butyl ester
- More information
- Acetone
- More information
- Acetylene
- More information
- Ammonia (anhydrous)
- More information
- Benzene
- More information
- Carbon monoxide
- More information
- Cyclohexane
- More information
- Cyclopentane
- More information
- Diesel fuel
- More information
- Ethane
- More information
- Ethanol
- More information
- Ethyl acetate
- More information
- Ethyl ether
- More information
- Ethylene
- More information
- Hexane
- More information
- Hydrogen
- More information
- Hydrogen sulphide
- More information
- Liquified petroleum gas (L.P.G.)
- More information
- Methane
- More information
- Methanol
- More information
- n-Butane
- More information
- n-Butanol
- More information
- n-Heptene
- More information
- n-Pentane
- More information
- n-Pentanol
- More information
- Nitrogen dioxide
- More information
- Nonane
- More information
- Octane
- More information
- Oxygen
- More information
- Petrol (unleaded)
- More information
- Propane
- More information
- Propylene
- More information
- Sulphur dioxide
- More information
- Toluene
- More information
- 1-Methoxy-2-propanol
- More information
- 1,2-Dimethylbenzene
- More information
- 1,3-Butadiene
- More information
- 2-Butanone
- More information
- 2-Methoxy-2-methyl-propane
- More information
Specifications 7
- Product
- Order number
- Dräger X-am 2800
- 3703900
- DrägerSensor CatEx SR
- 6851900
- DrägerSensor XXS CO LC
- 6813210
- DrägerSensor XXS H2S LC
- 6811525
- DrägerSensor XXS NO2
- 6810884
- DrägerSensor XXS O2
- 6810881
- DrägerSensor XXS O2 PR
- 6800530
- DrägerSensor XXS SO2
- 6810885
