Safety / Portable Gas Detection
Dräger X-am 3500
The Dräger X-am 3500 was especially designed for clearance measurements. The 1 to 4 gas detector reliably detects flammable gases and vapours as well as O2, CO, H2S, NO2 and SO2. The innovative signalling design and extensive range of accessories ensure optimum safety and easy handling.
Summary
Product overview
1 to 4 gas detection devicefor clearance measurementdetection of flammable gases and vapours as well as O2, CO, H2S, NO2 and SO2
Category
Portable Gas Detection
This page is structured from official Draeger content and reorganized for local B2B navigation.
Product enquiry
Enquire about Dräger X-am 3500
Send your project, quantity or specification request directly from the product page. The lead will be stored in the site CRM and can also be routed to email and Telegram notifications.
Specifications
Technical groups extracted from the official Draeger detail page.
Specifications 1
- Measurable gases
- Ex, O2, CO, H2S or NO2 or SO2
- Sensorports
- 4
- Number of gases
- 1 - 4
- Sensor technology
- CAT + EC
Specifications 3
- Operation time
- >24h
- Dimensions (W × H × D)
- 7.7x17.9x4.2 cm
- Weight
- 500 g
- Battery type
- Li-Ion
- Degree of protection (IP class)
- IP 68
Specifications 5
- ATEX
- I M1, II 1G, Ex da ia I Ma, Ex da ia IIC T4 Ga
- IECEx
- I M1, II 1G, Ex da ia I Ma, Ex da ia IIC T4 Ga
- c CSA us
- Class I, Zone 0, AEx da ia IIC T4 Ga Class II, Div 1, Gr. E, F, G
- GOST (EAC)
- PO Ex da ia I Ma X, 0Ex da ia IIC T4 Ga X
Specifications 6
- Name
- More information
- Acetic Acid
- More information
- Acetic acid butyl ester
- More information
- Acetone
- More information
- Acetylene
- More information
- Ammonia (anhydrous)
- More information
- Benzene
- More information
- Carbon monoxide
- More information
- Cyclohexane
- More information
- Cyclopentane
- More information
- Diesel fuel
- More information
- Diethylamine
- More information
- Ethane
- More information
- Ethanol
- More information
- Ethyl acetate
- More information
- Ethyl ether
- More information
- Ethylene
- More information
- Heptane
- More information
- Hexane
- More information
- Hydrogen
- More information
- Hydrogen sulphide
- More information
- Liquified petroleum gas (L.P.G.)
- More information
- Methane
- More information
- Methanol
- More information
- n-Butane
- More information
- n-Butanol
- More information
- n-Pentane
- More information
- Nitrogen dioxide
- More information
- Nonane
- More information
- Octane
- More information
- Oxygen
- More information
- Petrol (unleaded)
- More information
- Propane
- More information
- Propylene
- More information
- Propylene oxide
- More information
- Styrene
- More information
- Sulphur dioxide
- More information
- Toluene
- More information
- 1-Methoxy-2-propanol
- More information
- 1,3-Butadiene
- More information
- 2-Butanone
- More information
- 2-Methoxy-2-methyl-propane
- More information
- 2-Propanol
- More information
- 3-Pentanol
- More information
Specifications 7
- Product
- Order number
- DrägerSensor Cat-Ex 125 PR
- 6812950
- DrägerSensor XXS CO LC
- 6813210
- DrägerSensor XXS H2S LC
- 6811525
- DrägerSensor XXS NO2
- 6810884
- DrägerSensor XXS O2
- 6810881
- DrägerSensor XXS O2 PR
- 6800530
- DrägerSensor XXS SO2
- 6810885
