Dräger Polytron 3000
The Dräger Polytron 3000 is an intrinsically safe gas detector for the continuous monitoring of toxic gases and oxygen in ambient air. It is the part of a new generation of gas detectors developed on a modular platform. Communication to the central control system is done via a 4 to 20 mA signal.
Summary
Product overview
Monitors over 60 toxic gases and oxygen in ambient airUses a high-performance plug-and-play electrochemical DrägerSensorRobust, compact housing with IP66 protection
Category
Fixed Gas Detection
This page is structured from official Draeger content and reorganized for local B2B navigation.
Product enquiry
Enquire about Dräger Polytron 3000
Send your project, quantity or specification request directly from the product page. The lead will be stored in the site CRM and can also be routed to email and Telegram notifications.
Specifications
Technical groups extracted from the official Draeger detail page.
Specifications 1
- Type
- Transmitter
- Measuring Principle
- Electrochemical
- Cable entry
- M20
- SIL
- SIL 1 (IEC 61508-2)
Specifications 2
- Power Supply
- 12 to 30 V DC, 2-wire
- Temperature (operation)
- -40°C - 65°C
- Humidity
- 0 to 100% r.h., non-condensing
- Pressure (hPa)
- 700 - 1300
- Dimensions (H × W × D)
- 16.6x13.5x12.9 cm
- Weight
- 900 g
- Housing Material
- Glass fibre reinforced polyester (GFRP)
- Degree of protection (IP class)
- IP66
Specifications 4
- Name
- More information
- Acetic Acid
- More information
- Ammonia (anhydrous)
- More information
- Antimony pentachloride
- More information
- Boron tribromide
- More information
- Boron trichloride
- More information
- Boron trifluoride
- More information
- Bromine (gaseous)
- More information
- Carbon monoxide
- More information
- Chlorine
- More information
- Chlorine dioxide
- More information
- Chlorosulphonic acid
- More information
- Dichlorosilane
- More information
- Diethylamine
- More information
- Dimethylamine (anhydrous)
- More information
- Ethylamine
- More information
- Ethylene oxide
- More information
- Fluorine
- More information
- Formic acid
- More information
- Germanium tetrachloride
- More information
- Germanium tetrafluoride
- More information
- Hydrogen
- More information
- Hydrogen bromide (anhydrous)
- More information
- Hydrogen chloride (anhydrous)
- More information
- Hydrogen cyanide (anhydrous)
- More information
- Hydrogen fluoride (anhydrous)
- More information
- Hydrogen iodide solution (57%)
- More information
- Hydrogen sulphide
- More information
- Isopropylamine
- More information
- Methylamine (anhydrous)
- More information
- N,N-Dimethylethylamine
- More information
- Nitric acid, fuming
- More information
- Nitric oxide
- More information
- Nitrogen dioxide
- More information
- Oxygen
- More information
- Ozone
- More information
- Phosphorus oxychloride
- More information
- Phosphorus trichloride
- More information
- Silicon tetrachloride
- More information
- Silicon tetrafluoride
- More information
- Stannic chloride
- More information
- Sulphur dioxide
- More information
- Thionyl chloride
- More information
- Titanium tetrachloride
- More information
- Trichlorosilane
- More information
- Triethylamine
- More information
- Trimethylamine (anhydrous)
- More information
Specifications 5
- Product
- Order number
- DrägerSensor Acidic Compounds AC
- 6810595
- DrägerSensor Cl2
- 6809665
- DrägerSensor CO
- 6809605
- DrägerSensor CO LS
- 6809620
- DrägerSensor H2
- 6809685
- DrägerSensor H2S
- 6810435
- DrägerSensor HCN LC
- 6813200
- DrägerSensor NH3 HC
- 6809645
- DrägerSensor NH3 LC
- 6809680
- DrägerSensor NO
- 6809625
- DrägerSensor NO2 LC
- 6813205
- DrägerSensor O2 LS
- 6809630
- DrägerSensor OV
- 6809615
- DrägerSensor Ozone
- 6814005
- DrägerSensor SO2
- 6809660
