Dräger Polytron 6100 EC WL
The Dräger Polytron 6100 EC WL is a wireless transmitter for continuous monitoring of toxic gases and oxygen. The intrinsically safe and SIL2-rated transmitter features completely wireless signal transmission and power supply. The internal battery pack allows the transmitter to operate continually for up to 24 month. This makes the Polytron a flexible and cost efficient solution for plant expansions, upgrades or new installations.
Summary
Product overview
Wireless transmitter for continuous monitoring of toxic gases and oxygenInstrinsically safe and SIL2-ratedOperates continually for up to 24 months
Category
Fixed Gas Detection
This page is structured from official Draeger content and reorganized for local B2B navigation.
Product enquiry
Enquire about Dräger Polytron 6100 EC WL
Send your project, quantity or specification request directly from the product page. The lead will be stored in the site CRM and can also be routed to email and Telegram notifications.
Specifications
Technical groups extracted from the official Draeger detail page.
Specifications 1
- Type
- Wireless Transmitter
- Measuring Principle
- Electrochemical
- Cable entry
- M25 x 1.5
- SIL
- SIL 2 (IEC 61508-1-3) - optional
- HART®
- WirelessHART - optional
Specifications 2
- Power Supply
- Lithium-Thionyl Chloride Battery
- Temperature (operation)
- -40°C - 65°C
- Humidity
- 0 to 100% r.h., non-condensing
- Pressure (hPa)
- 700 - 1300
- Dimensions (H × W × D)
- 32x15x17 cm
- Weight
- 3.2 Kg
- Housing Material
- Stainless steel
- Degree of protection (IP class)
- IP66/67
Specifications 3
- UL
- optional
- CSA
- optional
Specifications 4
- Name
- More information
- Acetaldehyde
- More information
- Acetic Acid
- More information
- Acetic acid ethenyl ester
- More information
- Acetylene
- More information
- Ammonia (anhydrous)
- More information
- Antimony pentachloride
- More information
- Arsine
- More information
- Boron tribromide
- More information
- Boron trichloride
- More information
- Boron trifluoride
- More information
- Bromine (gaseous)
- More information
- Carbon monoxide
- More information
- Chlorine
- More information
- Chlorine dioxide
- More information
- Chlorosulphonic acid
- More information
- Diborane
- More information
- Dichlorosilane
- More information
- Diethylamine
- More information
- Dimethyl disulfide
- More information
- Dimethyl sulphide
- More information
- Dimethylamine (anhydrous)
- More information
- Disilane
- More information
- Epichlorohydrin
- More information
- Ethanol
- More information
- Ethyl ether
- More information
- Ethyl mercaptan
- More information
- Ethylamine
- More information
- Ethylene
- More information
- Ethylene oxide
- More information
- Fluorine
- More information
- Formaldehyde
- More information
- Formic acid
- More information
- Germanium tetrachloride
- More information
- Germanium tetrafluoride
- More information
- Germanium tetrahydride
- More information
- Hydrazine (anhydrous)
- More information
- Hydrogen
- More information
- Hydrogen bromide (anhydrous)
- More information
- Hydrogen chloride (anhydrous)
- More information
- Hydrogen cyanide (anhydrous)
- More information
- Hydrogen fluoride (anhydrous)
- More information
- Hydrogen iodide solution (57%)
- More information
- Hydrogen peroxide
- More information
- Hydrogen selenide (as Se) (anhydrous)
- More information
- Hydrogen sulphide
- More information
- Isopropylamine
- More information
- Isopropylmercaptan
- More information
- Methanol
- More information
- Methyl hydrazine
- More information
- Methyl mercaptan
- More information
- Methyl methacrylate
- More information
- Methylamine (anhydrous)
- More information
- N,N-Dimethylethylamine
- More information
- N,N-Dimethylhydrazine
- More information
- Nitric acid, fuming
- More information
- Nitric oxide
- More information
- Nitrogen dioxide
- More information
- Oxygen
- More information
- Ozone
- More information
- Phosgene
- More information
- Phosphine
- More information
- Phosphorus oxychloride
- More information
- Phosphorus trichloride
- More information
- Propyl mercaptan
- More information
- Propylene
- More information
- Propylene oxide
- More information
- Silane
- More information
- Silicon tetrachloride
- More information
- Silicon tetrafluoride
- More information
- Stannic chloride
- More information
- Styrene
- More information
- Sulphur dioxide
- More information
- Tetrahydrofuran
- More information
- Tetrahydrothiophene
- More information
- Thionyl chloride
- More information
- Titanium tetrachloride
- More information
- Trichlorosilane
- More information
- Triethylamine
- More information
- Trimethylamine (anhydrous)
- More information
- Vinyl chloride
- More information
- 1,3-Butadiene
- More information
- 2-Methyl-2-propanethiol
- More information
- 2-Propanol
- More information
Specifications 5
- Product
- Order number
- DrägerSensor Acidic Compounds AC
- 6810595
- DrägerSensor Cl2
- 6809665
- DrägerSensor CO
- 6809605
- DrägerSensor CO LH
- 6812570
- DrägerSensor CO LS
- 6809620
- DrägerSensor COCl2
- 6809930
- DrägerSensor H2
- 6809685
- DrägerSensor H2O2 HC
- 6809675
- DrägerSensor H2O2 LC
- 6809705
- DrägerSensor H2S
- 6810435
- DrägerSensor H2S HC
- 6809710
- DrägerSensor H2S LC
- 6809610
- DrägerSensor HCl
- 6809640
- DrägerSensor HCN
- 6809650
- DrägerSensor HCN LC
- 6813200
- DrägerSensor Hydride
- 6809635
- DrägerSensor Hydride SC
- 6809980
- DrägerSensor MEC H2 HC
- 6800335
- DrägerSensor N2H4
- 6810180
- DrägerSensor NH3 TH
- 6800055
- DrägerSensor NH3 HC
- 6809645
- DrägerSensor NH3 LC
- 6809680
- DrägerSensor NH3 TL
- 6813095
- DrägerSensor NO
- 6809625
- DrägerSensor NO2 LC
- 6813205
- DrägerSensor O2 LS
- 6809630
- DrägerSensor OV 1
- 6810740
- DrägerSensor OV 2
- 6810745
- DrägerSensor Ozone
- 6814005
- DrägerSensor PH3/AsH3
- 6809695
- DrägerSensor SO2
- 6809660
