Dräger Polytron® 8720 IR
With its stainless steel 316L enclosure and drift free optics, the Dräger PIR 7200 is built for the harshest industrial and commercial outdoor environments. The unique 4 beam signal stabilizing system makes the sensor resistant to dust or dirt deposi … More information
Summary
Product overview
Advanced explosion-proof transmitter for carbon dioxide detectionUtilizes high-performance infrared Dräger PIR 7200 sensorCompatible with most control systems via HART®, Modbus, and Fieldbus
Category
Fixed Gas Detection
This page is structured from official Draeger content and reorganized for local B2B navigation.
Product enquiry
Enquire about Dräger Polytron® 8720 IR
Send your project, quantity or specification request directly from the product page. The lead will be stored in the site CRM and can also be routed to email and Telegram notifications.
Specifications
Technical groups extracted from the official Draeger detail page.
Specifications 1
- Type
- Transmitter
- Measuring Principle
- Infrared
- Response time
- <= 8 seconds
- Cable entry
- M20 or 3/4" NPT
- SIL
- SIL 2 (IEC 61508-1-3)
Specifications 2
- Power Supply
- 10 to 30 VDC, 3-wire
- Temperature (operation)
- -40°C - 77°C
- Humidity
- 0 to 100% r.h., non-condensing
- Pressure (hPa)
- 700 - 1300
- Dimensions (H × W × D)
- 28x15x13 cm
- Weight
- 5.7 Kg
- Housing Material
- Epoxy coated copper-free aluminum or stainless steel SS316 L
- Degree of protection (IP class)
- IP65/66/67
Specifications 4
- Name
- More information
- Carbon dioxide
- More information
Specifications 5
- Product
- Order number
- PIR7200 424 NPT NON-HART for P5/8k
- 6813124
